GU256X32D-K610A8
VFD Display, Dot Matrix, 256 x 32, 14.25mm x 115mm, I2C / Parallel / SPI, 500 mA, 4.5 V to 5.25 V
Potrebujete več?
| Količina | |
|---|---|
| 1+ | € 139,970 |
| 5+ | € 132,290 |
| 10+ | € 124,510 |
INFORMACIJE O IZDELKU
Pregled izdelka
The GU256X32D-K610A8 is a Flexible Graphic VFD Module includes the VFD glass, VF drivers, microcontroller, character generation, interface logic and transformerless DC/DC converter. The interface type is selected by a push button on the back of the module. Auto key scanning and general I/O are available on port PA0 to PA7 for user control. Pixel Flexible, use a RISC processor for individual dot/cursor placement with SPI/I²C/RS485/RS232 plus user ports.
- 256 x 32 High brightness dot graphic display
- 4 ASCII fonts (5 x 5, 5 x 7, 10 x 14, 7 x 15)
- Asynchronous, SPI, I²C and parallel interfaces
- 8 user I/O pins with key scanning capability
Področja uporabe
Imaging, Video & Vision, Communications & Networking
Opozorila
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Tehnični podatki
256 x 32
Dot Graphic
5.25V
-40°C
I2C, Parallel, SPI
No SVHC (14-Jun-2023)
14.25mm x 115mm
4.5V
500mA
85°C
-
Tehnični dokumenti (1)
Zakonodaja in okoljevarstvo
Država, v kateri je bila izvršena zadnja pomembnejša dodelava.Drzava poreklaGreat Britain
Država, v kateri je bila izvršena zadnja pomembnejša dodelava.
RoHS
RoHS
Potrdilo o skladnosti izdelka
