HDE15PTD

The HDE15PTD from ITW Mcmurdo is a high density series 15 position D sub plug connector with DE shell size. High density series are most versatile connectors. This connector has UL94 V-0 rated thermoplastic insulation.

• Tinned and dimpled steel shell for EMI/RFI shielding
• Copper alloy contacts with hard acid gold plating
• Solder bucket termination
• Standard fixing holes
• High temperature range from -55°C to 105°C
• Current rating of 3A for individual contact (in isolation) at 70°C
• Current rating of 2A for all contacts (simultaneously) at 70°C
• Working voltage of 300V (DC or AC peak)
• Maximum contact resistance of 15mohm
• Minimum insulation resistance of 1000mohm

Področja uporabe

Communications & Networking, Computers & Computer Peripherals, Industrial
